RG11/U BC FPE 95% BC PE Cable CCTV Transmission Line RG11 Communication Cable Rg11 Coaxial Cable

Name: RG11U BC FPE 95 BC PE Cable CCTV Transmission Line RG11 Communication Cable Rg11 Coaxial Cable
Brand: Zion communication OR OEM
Price: 1 USD

Brand Name : Zion communication OR OEM

Model Number : RG11 Coaxial Cable

Certification : ISO, UL, CE, RoHS

Place of Origin : China

MOQ : 30 KM

Payment Terms : T/T, L/C

Supply Ability : 3000KM / Month

Delivery Time : 25 working days

Packaging Details : 305M, 1000FT, Wooden Reel, Carton

Conductor : 14AWG BC

Insulation : Foamed Polyethylene

Shield : Bare Copper(95%)

Jacket : PE

Color : Black, White

Package : 305M, 1000FT, Wooden Reel, Carton

Contact Now

RG11/U BC FPE 95% BC PE 75 Ohm CCTV coaxial Cable NO.7100261



Construction Parameters:
Inner Conductor		0.064"/1.63mm/14AWG BC
Dielectric		0.144"/7.11mm Foamed Polyethylene
Shield		Bare Copper(95%)
Jacket		0.4"±0.006"/10.3mm±0.15mm PE
Application		For Use in Longer CCTV Run Lengths
Electrical Characteristics:
Inner Conductor Resistance		8.25 Ohms/KM at 20℃

Capacitance		16.2±0.35 pF/ft
Impedance		75 ± 3 Ω
Return loss		between 5 and 1000MHz: > 23dB
Velocity of Propagation		0.82
Sparker Test (VAC)		3

Mechanical and Envrionmental Properties
Cable bend radius		10 times the cable diameter
Operating Temp Range		-20 ℃ to 60℃
Cable diamensions		0.4"±0.006"/10.3mm±0.15mm PVC

Cross Section














Attenuation(20℃):
Frequency (MHZ)		Max Attenuation(dB/100ft)
5
10		0.35
50		0.87
100		1.38
200		1.98
400		2.95
700		4.00
900		4.54
1000		4.70

Order Informations:
Marking		HELLOSIGNAL RG11/U BC FPE 95% BC PE CCTV COAXIAL CABLE 7100261 ×××M/FT
Package		Inquired Length on wooden Spool,pallet …
Delivery time		Normally 25 days after received the deposit.
Brand		HELLOSIGNAL® OR OEM
